240W Shoebox LED Parking Lot Lights Photocell Sensor for Parking Lot
| Wattage: | 240w |
| Colour Temperature: | 2700K-6700k |
| Lumen: | 31200lm |
| IP: | IP65 |
| Input Voltage: | 100-277VAC 200-480VAC |
| Warranty: | 3/5 Years |
| Certification: | ETL DLC SAA CE ROHS Listed |
| Power | 240w |
| Model | BB-LD-240W-S-X-YY-DRZ-V-UU |
| Luminous Flux | 31200lm |
| Replacement | HPS 700W |
| Light Source | SMD LED |
| Luminous Efficacy | 130lm/W |
| Operation Temp | -40 to +45℃ |
| CCT | 2700K SW / 3000K WW / 4100K NW / 5000K DW / 5700K CW / 6500K SCW |
| CRI | 80+ |
| Life Span | 50,000 hours at 25℃ |
| Voltage | 100-277VAC/50-60HZ 200-480VAC/50-60HZ |
| With sensor | No sensor, Motion sensor, Photocell sensor, Optional |
| Microwave sensor default setting | Someone brightness 100%, microwave sensitivity 75%, hold time 5 minutes, start illumination 50LUX, continuous brightness 30%, the duration of 30 minutes. |
| IP | IP65 |
| PF | >0.95 |
| Warranty | 3/5 Years |
What are the advantages of 240W Shoebox LED Parking Lot Lights Photocell Sensor for Parking Lot?
1.Replace conventional shoebox light.
2.Precision die cast aluminum housing.
3.Durale chip and fade resistant power coat finish.
4.Easy installation.
5.CE ROHS listed.
6.California new policy request shoebox have to need 3 step dimming with sensor.
What are the features of 240W Shoebox LED Parking Lot Lights Photocell Sensor for Parking Lot?
1.Aluminum die casting heat sinks is good for heat dissipation.
2.It’s major to replace the conventiona shoebox light.
3.Green ,energy saving,long and relialble life of 50,000 hours.
4.No RF interference ,no IR / UV radiation,no mercury pollution.
5.Wide colour availability in degrees Kelvin(K),2700-6700K.
6.Streamline exterior design,beautiful appearance.
7.Environment friendly ,energy saving (70%~80%).
8.Special circuit design,each LED work separately,avoiding the single broken LED influence problem.
What are the applications of 240W Shoebox LED Parking Lot Lights Photocell Sensor for Parking Lot?
1.Area lighting,street lighting.
2.Architectural decorative lighting.
3.Industrial lighting.
4.Stadium lighting.
5.Port wharf lighting.
6.Roadway lighting.
FAQs
Q1. Can I have a sample order for led light?How to order samples?
A1: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.Send inquiry at contact page,we will contact with you,and send you quotation.
Q2.What’s your payment term?Can you accept the Credit Card?
A2:We accept payment by Alibaba / TT / Western Union / Paypal / Visa.We accept payment by credit card.
Q3. What about the lead time?
A3:Sample needs 1-5 days, mass production time needs 1-2 weeks for order quantity more than 8000pcs.
Q4. Do you have any MOQ limit for led light order?
A4: Low MOQ, 1pc for sample checking is available.
Q5.What are the temperture color you can provide?
A5:We can provide 2700K SW / 3000K WW / 4100K NW / 5000K DW / 5700K CW / 6500K SCW.
Q6. How do you ship the goods and how long does it take to arrive?
A6: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q7. How to proceed an order for led light?
A7: Firstly let us know your requirements or application.
Secondly we quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal orders.
Fourthly We arrange the production.
Q8. Is it OK to print my logo on led light product?
A8: Yes. Please inform us formally before our production and confirm the design firstly based on the sample.
Q9: Do you offer guarantee for the products?
A9: Yes, we offer 3-5 years warranty to our products.
Q10: How to deal with the faulty?
A10: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
Evaluate this 240W shoebox option for a parking lot or outdoor area-lighting project. Confirm the complete configuration against your site’s lighting requirements, supply voltage, pole interface and control plan before ordering.
Request a project quotation · Browse LED shoebox lights · Read the selection guide
Match the light to the site
Use the selected optic’s IES file to review the planned pole height, spacing and fixture orientation. Check the project’s lighting criteria and boundary conditions. Wattage and a catalogue lumen value alone do not establish the required number of fixtures.
Share the pole shape, arm or tenon dimensions and existing mounting arrangement. Confirm which bracket and adapter are supplied before installation.
Controls and photocell selection
Specify whether you need a photocell, motion control or operation without a sensor. Include any dimming requirements in your enquiry.
For dimming or motion control, confirm the control signal, compatible driver, wiring and operating sequence. Request the installation instructions for the supplied configuration.
Product documents
Series specification sheet. Request documents for your project quotation, including photometric data, installation instructions and documents required for your target market.
Selection questions
Should I choose 240W or 200W?
Compare this option with the 200W option using the project’s lighting criteria and the selected optics’ IES data. Review rated output, maintained lighting, uniformity and light spill for the actual layout. Power alone does not determine the choice.
Can one fixture work on every voltage listed in a series sheet?
Confirm the exact driver version for the site’s supply. Alternative voltage versions in a series document do not mean each fixture supports the combined range.
Is a photocell included?
Specify whether you need a photocell and check the component list, interface and driver compatibility in your quotation.
How do I check mounting compatibility?
Provide the pole or arm details and request the fixture’s mounting drawing, dimensions and included hardware list. Confirm compatibility before selecting accessories.
Request a project quotation
- Project country and target market; site plan or dimensions; parking, pedestrian and boundary areas.
- Required lighting criteria from the project specification, including maintained illuminance and uniformity.
- Quantity; existing fixtures and system wattage; pole height, spacing, positions and mounting details.
- Supply voltage and frequency; requested CCT, operating schedule, dimming and photocell or motion-control requirements.
- Required product documents and market-specific evidence; quotation deadline; required delivery date.
Request a project quotation. Paste this product page URL into the message so the enquiry identifies the option you are reviewing. Ask for the confirmed configuration, documents, quantity pricing and current delivery terms.
