Indoor Linear LED Lighting 8FT 80W

SPECIFICATIONS

Construction Strong, durable formula for long-lasting color.

Die-cast aluminum end caps with magnetic interface.

Independent LED uplighting modules are available.

The diffuser and end caps at the ends of the fixture overlap to eliminate gaps and LED visibility.

Custom pattern with optional for Line, L, X, T, Y, V joiners.

Suspended, surface or wall mount in 2′, 4′, 6′, 8′ lengths.

Finish

It’s available in White, black, painted aluminum or custom color.

Lifespan Estimated 50,000-hour LED lifespan based on IES LM-80 results and  TM-21 calculations.

Controls Optional integrated sensor for daylight dimming and/or occupancy detection (optional).

Optional for Bluetooth controller or Bluetooth sensor.

Optional emergency battery backup.

Installation Pendant: steel wire rope mount.

Surface: For dry ceiling or T-Grid ceiling and wall mounting.

Recessed: Trimless recess/trim visible recess/drop ceiling recess/dry wall recess mount.

Electrical Universal 120-277 VAC input voltage.

Standard with 0-10V dimming driver and dimming range from 0-100%.

Both drivers have a power factor >90%, THD <20%

Optional for power adjustable: 100%, 75%, 50%.

Highly efficient and durable Class II drivers are available.

Operating Temperature Range: -20°C to 40°C (-4˚F – + 104˚F).

Warranty Five-year limited warranty.

Certifications UL cUL damp location listed.

Note

Actual performance may differ as a result of end-user environment

and application. All values are design or typical values, measured

under laboratory conditions at 25℃(±5℃ ) specifications subject to

change without notice.

Optics

Optional dual circuit switching for independent dimming of indirect

and direct light outputs.

Optional for five level Light Distribution by dip switch.

Light engines are available in CCT adjustable:

2700K/3000K/3500K/4000K/5000K.

Optional anti-glare UGR louver reflectors with UGR<19, or batwing distribution.

Scalable lumen packages from 2,400 to 9,600 lumens and up to 120 lm/W.

<3 SDCM color consistency, 80CRI, or 90 CRI option.

High-quality flat frost diffuser for smooth light distribution and uniformity

DIM TO WARM

Frosted diffuser provides soft and

Create a comfortable atmosphere and provide a better visual experience.

Be highly energy-efficient and effectively reduce heat emissions.

Be compatible with intelligent control systems and adapt to various application scenarios.

The brightness and color temperature of the light can be flexibly adjusted according to different scenes and needs, providing a richer visual experience.
