Linear High Bay Lights 320W High Bay Linear

Model: BB-GKD-320W-A7
SKU: BB-GKD-320W-A7
Download: Spec Sheet
Power 320W
Model BB-GKD-320W-A7
Luminous Flux 38400lm
IP IP65
Input Voltage 100-277VAC 200-480VAC
Warranty 3 Years
Certification: Ul Dlc Ltisd
Please Send Inquiry, we'll get back to email you in 12 hours.
Power 320W
Model BB-GKD-320W-A7
Luminous Flux 38400lm
Beam Angle 120°
Materials Galvanized Sheet + PC
Luminous Efficacy 120/lm/W
Operation Temp -40 to +45℃
CCT 2700K SW / 3000K WW / 4100K NW / 5000K DW / 5700K CW
CRI 80+
Life Span 50,000 hours at 25℃
Voltage 100-277VAC/50-60HZ 200-480VAC/50-60HZ
IP IP65
PF >0.95
Warranty 3 Years

LED LINEAR HIGH BAY lights is a device which are consist of galvanized sheet frame, LED light source model and driver. It can be a replacementof HID and other tradional light fixture, provided with higher efficacy, a longer lifeme 50,000H at least or even more upto100,000H and very lower breakdown opportunity, higher reliability and beer cost than any light before.The highperformance, providing significant energy savings while remaining durable in the field.

European and American design style, high quality galvanized sheet, Surfacepainng process, never fade, an-cracking.Adopt aerodynamic design, take heat away quickly, keep low temperature for heat sink and LED chip for longer lifespan and higher light efficiency.

Two installaon method: Chain and Rod. All the screws are 304stainless steel screws with stronger corrosion resistance ability.Use branded led chip, high CRI, No flicker, no dazzle, meanwhile very healthy to the eye.

Through various of experimental tests: wind resistance level test, conducon radiaon, 1.5G seismic test, UV aging test, drop, stacking test etc.
MOTION SENSOR TECHNOLOGY – Included is an infrared sensor which detects moon up to 80 feet away. Simply walk into range to power the light on. For safety and security reasons, the high bay fixture dims if no movement is detected aer 2 minutes.

Smart Oponal: Microwave Sensor/ APP/WiFi /Bluetooth

We have over 15 years of commercial lighting R&D experience, 50+ LED lights patents, 200+ LED Lights Certifications, Support OEM & ODM, 3/5 Years Warranty. Which can be widely used in commercial, industrial, residential, and other different occasions.Our factory has an experienced and skilled R&D team, dedicated to constantly innovate, improve product performance and quality. We also have a complete production line, from design, manufacturing to testing, every link goes through strict quality control, to ensure that each product can meet the needs and expectations of customers. We also provide comprehensive after-sales service, providing technical support and maintenance services to make customers' experience more smooth and satisfactory.BBIER® adheres to the principle of "quality first, customer first", and is committed to providing customers with high-quality products and services, becoming a trusted partner of customers. We will continue to innovate and improve, bring more value and contribution to customers.
